- Protection class
- IP67
- Switching element function
- NO/NC programmable
- Output function
- PNP/NPN
- Approvals
- cULus
- Design
- Without display (integrated probe)
- Process connection
- For compression fittings, thermowell or direct mounting
- Immersion depth L (mm)
- 200
- Detection type
- medium contact
- Communication protocol
- IO-Link
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 80
- Mounting conditions
- Immersion sensor
- Operating voltage
- DC
- Measuring range
- -50…350 °C
- Electrical output
- Current output (2-wire), Switching output
