PROFIBUS quick-action connector VAZ-PB-DB9-W

PROFIBUS quick-action connector VAZ-PB-DB9-W

  • Brand:Pepperl+Fuchs
  • Product Code: VAZ-PB-DB9-W
  • Availability: Out Of Stock

PROFIBUS Sub-D Connector with switchable terminal resistance

Datasheet excerpt: Technical data of  VAZ-PB-DB9-W

Product Description
PROFIBUS Sub-D Connector with switchable terminal resistance
Electrical specifications
Rated operating voltage60 V AC
Rated operating current1 A
Interface
ProtocolPROFIBUS
Transfer ratemax. 12 MBit/s
Ambient conditions
Ambient temperature-20 ... 75 °C (-4 ... 167 °F)
Storage temperature-25 ... 80 °C (-13 ... 176 °F)
Mechanical specifications
Core cross-section0.12 mm2 to max. 0.5 mm2 solid
Degree of protectionIP40
Connection9-pin Sub-D connector (pins)
Material
Housingmetallized ABS
Cable
Sheath diameter7.6 mm ... 8.4 mm

Classifications

SystemClasscode
ECLASS 13.027242692
ECLASS 12.027242692
ECLASS 11.027242692
ECLASS 10.0.127242692
ECLASS 9.027242692
ECLASS 8.027279212
ECLASS 5.127279212
ETIM 9.0EC003015
ETIM 8.0EC003015
ETIM 7.0EC003015
ETIM 6.0EC003015
ETIM 5.0EC003015
UNSPSC 12.139121535
