Incremental Encoder REI-04Q6C-2H2500-H1181
- Brand:TURCK
- Product Code: 100011155
- Availability: Out Of Stock
- Protection class
- IP65
- Output function
- Push-Pull/HTL
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Aluminum chromated
- Ambient temperature min. (°C)
- -20
- Ambient temperature max. (°C)
- 85
- Measuring principle
- Optical
- Output type
- Incremental
- Shaft Type
- Solid shaft
- Shaft diameter D (mm)
- 6
- Flange diameter (mm)
- 36.5
- Flange type
- Clamping flange
- Resolution incremental (ppr)
- 2500
