Pressure Transmitter PT20PSIG-1005-I2-H1143
- Brand:TURCK
- Product Code: 6837452
- Availability: Out Of Stock
- Protection class
- IP67
- Output function
- Analog output current
- Approvals
- cULus
- Design
- Without display
- Process connection
- 7/16″-20 UNF male thread
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Media temperature min. (°C)
- -40
- Media temperature max. (°C)
- 125
- Ambient temperature min. (°C)
- -30
- Ambient temperature max. (°C)
- 85
- Operating voltage
- DC
- Electrical output
- Current output (2-wire)
- Pressure type
- Relative pressure
- Material pressure transducer
- Ceramic Al₂O₃
- Pressure range
- 0…1.38 bar
