Isolating switching amplifier IM18-DI03-4S-4T1R-SPR/24VDC/CC
- Brand:TURCK
- Product Code: 100030006
- Availability: Out Of Stock
- Protection class
- IP20
- Electrical connection
- Removable spring-type terminals, 3-pin
- Housing material
- Plastic
- Housing quality
- Polycarbonate/ABS
- Ambient temperature min. (°C)
- -25
- Ambient temperature max. (°C)
- 70
- Power supply
- 24 VDC
- Number of channels
- 4
- Ex version
- no
- Signal type
- Digital input
- Nominal voltage
- Power bridge 24 VDC
- Digital output
- Transistor output
